Ziplock Bag Making Machine
Ziplock Bag Making Machine Equipped with a photocell for precision monitoring, this machine features a user-friendly touchscreen interface. It utilizes a stepper motor along with an inverter for optimal speed regulation. The adjustable bag length capability further enhances production efficiency, significantly decreasing labor and time demands.
ziplock bag
Main Technical Variables:
Model | ZIP-500 | ZIP-600 |
Material | LDPE | LDPE |
Capacity | 50-150(Cycle/min) | 50-130(Cycle/min) |
Cutting width | 100-500mm | 120-600mm |
Cutting length | 120-300mm | 150-400mm |
Thickness of film | 0.04-0.15mm | 0.04-0.15mm |
Film annulus diameter | Φ550×500mm | Φ550×600mm |
Heater | 2kw | 2.5kw |
Cooling | 0.37kw | 0.37kw |
Power | 3kw | 3.5kw |
Outline dimension(L×W×H)
|
3200×1100×1500mm | 3300×1100×1500mm |
Bag Material | LDPE,recycle film | |
Bag | Zip Bag, Self lock Bag | |
Bag Color | Transparent,Black,Red,White,blue bag,color changed by Color masterbatch | |
Power Voltage | 220V | |
Material Core Diameter | 58mm,76mm | |
Machine Working Time | 24 hours * 7 days | |
Warranty | 1 year |
If you only buy one machine,we will pack machine with wooden pack,and loading container with Less Than Container Load(LCL).
Our Main parts cooperator as following brand,but standard parts all made from China.
China Evergreen Machinery Co., Ltd. is a manufacturer and supplier of plastic film and plastic bag production equipment for the entire factory, including blown film machines, bag making machines, flexible printing machines, copper tube machines, recycling extruders, stretching film machines, and foaming machines.
