Three Side Sealing Bag Making Machine
Inquiry Basket
OEM：
Available
Sample：
Available
Port：
Ningbo
Payment：
PayPal,VISA,MasterCard,Western Union,L/C,T/T
Place of Origin：
China
Shipping：
Sea freight · Land freight · Air freight
Supply Ability：
300 unit per Year
Product Details
Three side Sealing Bag Making Machine
The Three Side Sealing Bag Making Machine is engineered with a sophisticated structure that promotes user-friendly operation and a high degree of automation. This equipment efficiently produces three side sealing pouches from a range of laminated materials, such as plastic-plastic, paper-plastic, and paper-paper configurations.
A centralized PLC control system oversees the entire operation, ensuring effective communication between the operator and the machine. This leads to improved performance stability, along with more straightforward operation and maintenance. Moreover, users can effortlessly toggle between Chinese and English interface languages.
Notable features of the machine include automatic tension control for unwinding, an EPC edge position controller, and an AC inverter that maintains consistent speed during automatic material feeding. Additionally, it incorporates an imported double servo-motor system for precise control of material dragging.
Main Technical Variables:
| KDZD-A500 | KDZD-A600 | |
| Max.Diameter of roll material | 600mm | 600mm |
| Max.Width of roll material | 1050mm | 1250mm |
| Max.Capacity | 160 section/min（pieces/mm） | 160 section/min（pieces/mm） |
| Max.Mechanical speed | 40meter/min | 40 meter/min |
| Total Power | 40Kw | 40Kw |
| Weight | 4500kg | 5500kg |
| Outline Dimension | 9000x1900x1900mm | 9000x2000x1900mm |
If you only buy one machine,we will pack machine with wooden pack,and loading container with Less Than Container Load（LCL）.
Our Main parts cooperator as following brand,but standard parts all made from China.
