High Speed Eight Colors Flexo Printing Machine
The Eight Colors Flexo Printing Machine utilizes sensitization resin in its flexible printing plate and is meticulously designed for the printing of various packaging materials, such as polyethylene and polypropylene bags, cellophane, and roll paper. This machine is particularly adept at producing paper packaging bags for retail items, supermarket shopping bags, vest bags, clothing bags, and similar products.
Noteworthy for its operational efficiency, the Eight Colors Flexo Printing Machine features an intuitive user interface and precise color registration capabilities. It includes a meter counter that enables accurate monitoring of the printing quantity, automatically stopping the machine upon reaching the desired number or when material levels are low. Additionally, the pneumatic printing cylinder facilitates ink stirring after lifting, while the anilox cylinder ensures consistent ink application.
| YT-A8600 | YT-A8800 | YT-A81000 | YT-A81200 | |
| Max.material width | 600mm | 800mm | 1000mm | 1200mm |
| Max.printing width | 560mm | 760mm | 960mm | 1160mm |
| Printing colors | 8 colors (8+0,7+1,6+2,5+3,4+4) | |||
| Printing length | 300-1000mm | |||
| Machine speed | 150m/min | |||
| Printing speed | 100m/min (120m/min with optional:chamber doctor blade) | |||
| Suitable Material | PAPER∶15~300g/m²、 NONWOVEN∶15-120G、PC∶10-120μm、OPP∶10-100μm、BOPP∶10-100μm、PE∶15-150μm、NY∶10-120μm、 PET∶10-100μm、CPP∶10-100μm | |||
| Adjusting of register | Electric motor control (vertical and horizontal) | |||
| Material of Plate | Resin | |||
| Constitution of Printing | Ceramic Anilox roller 8pcs、single doctor blade 8pcs、printing Cylinder for printing length 400mm、 Camera & PLC touch screen control
|
|||
| Optional device :chamber doctor blade; | ||||
| Working Principle | synchronous belt driving | |||
| Printing precision | +/-0.15mm | |||
| Thickness of Plate (including the glue) | 1.7mm (please note us for different thickness) | |||
| Machine Voltage | 380V 50/60HZ 3PH | |||
※Correct specifications depend on the actual model. All specifications are subject to change without prior notice.
